Custom oil filter cartridge stainless steel pleated filter element

Short Description:

Filter media for Pleated Filter Elements are stainless steel sintered fiber felt and stainless steel woven wire cloth.


Product Detail

Product Tags

Filter Media: Stainless Steel woven mesh or sintered metal fiber
Stainless steel sintered fiber felt is a honey comb filter hole with high filtration rate. And it is a kind of durable and pleating-able, enough pleating can get bigger filtration area. Sintered into a graded pore structure, enjoys the advantages of high porosity rate, more filtration area, high dirt holding capacity and can be repeatedly used.

Stainless steel woven wire cloth is made by weaving of stainless steel wire in a variety of diameters. Filter elements with stainless steel woven wire cloth as filter medium, enjoy such advantages of good strength, fastness, easily cleanable, heat-resistance and economic cost.

Alloy: Stainless Steel, Duplex SS, Supper Duplex SS, Monel, Hastelloy, Inconel, FeCr Al, Fe3Al etc.

Superior Characteristic

-Large filtration area and particle holding capacity;
-High porosity rate, good air permeability and filtration ability;
-Suitable for viscous liquid filtration, recycled using after cleaning;
-Workable in High temperature or and high pressure.
Specification:

Technical specification

-Filtration rate: 3-200μm
-Temperature: -50℃-800℃
-Diameter:14-180mm, Length:35-1500mm
-Hanke Filter can be customized by your demands.

Product application

-High polymer industry;
-BOPP industy
-Petrochemical, petroleum refining
-Pharmaceutical and food refining or cycling
-Hydraulic machine
-Gas controlling
-Water treatment

Custom oil filter cartridge stainless steel pleated filter element

Model

L
(mm)

D
(mm)

M

Filter Area
(M2)

R
(µm)

Filter Media

PF-86/200-R

200

86

M65x2P

0.20

3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75

SS sintered fiber wed,
SS wire cloth

PF-86/350-R

350

0.35

PF-86/500-R

500

0.50

PF-100/800-R

800

100

M80x2P

1.00

Custom oil filter cartridge stainless steel pleated filter element

Model

L
(mm)

D
(mm)

M

Filter Area
(M2)

R
(µm)

Filter Media

PF-65/250-R

250

65

226
223
220
215

0.135

3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75

SS sintered fiber wed,
SS wire cloth

PF-65/500-R

500

0.38

PF-70/750-R

750

70

0.42

PF-70/750-R

750

0.60

Custom oil filter cartridge stainless steel pleated filter element

Model

L
(mm)

D
(mm)

M

Filter Area
(M2)

R
(µm)

Filter Media

PF-35/102-R

102

35

   M18
M20*2.5
M20*1.5
NPT1"
3/4 - 16

0.026

3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75

SS sintered fiber wed,
SS wire cloth

PF-35/207-R

207

0.07

PF-35/210-R

210

0.07

PF-35/242-R

242

0.08

PF-35/425-R

425

 0.15

PF-35/485-R

485

0.20

Custom oil filter cartridge stainless steel pleated filter element

Model

L
(mm)

D
(mm)

M

Filter Area
(M2)

R
(µm)

Filter Media

PF-62/180-R

180

62

G1"

0.09

3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75

SS sintered fiber wed,
SS wire cloth

PF-86/254-R

254

 86

   G2"

0.17

PF-86/381-R

381

0.20

PF-86/508-R

508

0.27

PF-86/760-R

760

0.58

PF-140/760-R

760

140

0.65

Custom oil filter cartridge stainless steel pleated filter element

Model

L
(mm)

D
(mm)

M

Filter Area
(M2)

R
(µm)

Filter Media

PF-60/1432-R

1432

60

2" * 12UN - 2A

1.015

3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75

SS sintered fiber wed,
SS wire cloth

PF-60/1241-R

1241

0.98

PF-60/1025-R

1025

0.81

Custom oil filter cartridge stainless steel pleated filter element

Model

L
(mm)

D
(mm)

M

Filter Area
(M2)

R
(µm)

Filter Media

PF-60/400-R

400

60

M33 * 1.5P
M33*2P

0.40

3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75

SS sintered fiber wed,
SS wire cloth

PF-60/500-R

500

0.50

PF-60/1000-R

1000

1.00
